JOYAL Industrial Vibrator

Industrial Vibrator feature simple structure easy maintenance and operation long service life low cost

Contact   |   Link To Product   |   More Products By This Company

Images

Click on an image to see larger size image ...

Specifications

Details

The Industrial Vibrator can send shaped and granule materials into receiving equipment evenly, timely and continuously. The Industrial Vibrator can feed the crusher continuously and classify the material primarily in sand production line. The Industrial Vibrator is widely used in crushing and sieving production line such as metallurgy, building material, chemical industry, coal, mining and mill.

Working Principle Of Industrial Vibrator:

The Industrial Vibrator is mainly used to feed material into the primary crusher homogeneously and continuously. Meanwhile, the Industrial Vibrator can screen material, making the crusher more powerful.Proven performance and maintenance free operation make our Industrial Vibrator
s the first choice in feeders for the most demanding applications including public utilities, mining, metals production, food processing, cement, and other industries.

Features Of The Industrial Vibrator in my company Shanghai Joyal Mining Machinery Co., Ltd.:

1.Smoothly vibrating, Long service life
2.Vibrating force adjustable, Flow rate changeable and controlled at any time
3. Low noise and power consumption
4. Simple Structure, convenient installation and using

Main Specifications Of Industrial Vibrator in my company:
Model Size of Funnel (mm) Max. Feeding Size (mm) Capacity (t/h) Motor Power (kw) Weight (kg) Overall Dimension (mm)
GZD-750×2500 750×2500 300 50-80 3 1590 2580×1100×1400
GZD-850×3000 850×3000 400 80-120 7.5 3895 3110×1800×1600
GZD-960×3800 960×3800 500 120-210 11 3980 3850×1950×1630
GZD-1100×4200 1100×4200 580 200-430 15 4170 4400×2050×1660
GZD-1100×4900 1100×4900 580 280-500 15 4520 5200×2050×1700
GZD-1300×4900 1300×4900 650 450-600 22 5200 5200×2350×1750
GZD-1500×6000 1500×6000 800 500-700 30 8670 6082×2995×2095

Tags

industrial vibrator, vibrating feeder, feeding machine, feeder machine
