AVL Vehicle GPS Tracker

SWS-VT300 is a low cost GPS/GSM/GPRS tracking device which is specially developed and designed for vehicle real-time tracking and security. With superior GPS and GPRS modules, SWS-VT300 has good sensitivity and stable performance.

Contact   |   Link To Product   |   More Products By This Company

Images

Click on an image to see larger size image ...

Specifications

Details

SWS-VT300 is a low cost GPS/GSM/GPRS tracking device which is specially developed and designed for vehicle real-time tracking and security.

With superior GPS and GPRS modules, SWS-VT300 has good sensitivity and stable performance. It can get accurate GPS fix even in remote places.

Main Features:

> Tracking via SMS or GPRS
> Current location report
> Tracking by time interval
> Emergency alert
> Geo-fencing control
> Low battery alert
> Speeding alert
> Alert when enter/exit GPS blind area
> Display Location Picture Directy on Mobile Phone by SMS
> Engine cut
> SOS panic button

Specification :

> Dimensions: 115mm x 60mm x 21mm
> Installation Dimension: 115mm x 79mm x 21mm
> Weight: 145g
> Frequency: GSM 900/1800/1900Mhz or GSM 850/900/1800/1900Mhz (optional)
> GPS Chipset: latest GPS SIRF-Star III chipset
> GPS Sensitivity: -158Db
> GPS Frequency: L1, 1575.42 MHz
> C/A Code: 1.023 MHz chip rate
> Channels: 20 channel all-in-view tracking
> Position Accuracy: 10 meters, 2D RMS
> Velocity Accuracy: 0.1 m/s
> Time Accuracy: 1 us synchronized to GPS time
> Default datum: WGS-84
> Reacquisition: 0.1 sec., average
> Hot start: 1 sec., average
> Warm start: 38 sec., average
> Cold start: 42 sec., average
> Altitude Limit: 18,000 meters (60,000 feet) max.
> Velocity Limit: 515 meters/second (1000 knots) max.
> Backup Battery: 850mAh
> Power Supply: +9V - +35V / 1.5A
> LED: 1 LED light to show working status.
> Button:One SOS button
