2CH mini HD DVR

Newly launched 2CH mini HD DVR with motion detection, support PIP monitor&32G SD

Contact   |   Link To Product   |   More Products By This Company

Images

Click on an image to see larger size image ...

Specifications

Details

Features:



1. D1/QVGA video resolution selectable

2. Video at D1 resolution: 720X576,QVGA resolution 360X288

3. Pictures at D1 resolution: 720X576,

4. 1 camera recording frame: Pal 25f/s. NTSC 30f/s.

5. 2 cameras recording frame 15f/s, another camera is taking photo

6. 32GB SD/SDHC memory supported

7. Motion detection supported

8. 5s/10s per video clip when motion detected

9. Continuously recording by manually operate

10. Picture-in-Picture (PIP) real time viewing

11. Overwrite automatically when memory full

12. Connect with PC to playback by USB cable


Parameter:



Item
Parameter

AV Input
3RCA input (2 video+1 audio)

Av output
2RCA output (1video+1 audio)

Frame
Pal:25f/s, NTSC:30f/s

Resolution
D1:720X576

QVGA:720X480

Compression
M-JEPG & Standard JPEG

Detect mode
Motion detection

Recording mode
Video recording & take photos

Memory
SD/SDHC Card,≤32GB

USB jack
USB 2.0

Power
DC12V (5V-36V made by order)

Working electricity
≤250Ma

Working Temperature
-10℃~+50℃

Operation Humidity
20%~85%

DVR Weight
160g

DVR Dimension
101X105X26 (LxWxH)

Tags

dvr camera, standalone dvr, 2ch dvr, motion detection, pip monitoring, 30fps, video recording, MJPEg, 32g sd recording, D1
